Takeuchi TB 180 FR 8.3t 2006-2014 - Technical data

TB180FR – Product Description

Powertrain and Design

The TB180FR mini excavator from Takeuchi is powered by a Yanmar 4TNV98 engine, delivering 64.6 hp (48.2 kW). Compliant with EPA Interim Tier 4, this machine is designed for tasks in challenging conditions. Its zero swing design allows operators to optimize maneuverability while maintaining stability.

Undercarriage and Hydraulics

The TB180FR features an undercarriage with rubber or steel tracks, measuring 17.7” (450 mm) in width. The efficient hydraulics include twin variable displacement piston pumps, providing a hydraulic flow rate of 52.5 gal/min (198 L/min), supporting high efficiency in both primary and auxiliary hydraulic circuits.

Operating Parameters

This machine achieves a maximum digging depth of 14 ft 11 in (4,545 mm) and a maximum dump height of 14 ft 8 in (4,470 mm). With a maximum reach of 23 ft 7 in (7,195 mm) and a breakout force of 16,335 lbs (7,409 kg), the TB180FR stands out for its extensive operational capabilities.

Optional Equipment

The TB180FR can be equipped with various attachments such as buckets and grapples, enabling it to perform specific construction tasks. The ability to connect to additional implements enhances the machine's versatility in the field.

Safety and Technical Data

This machine is fitted with protective glass, low-profile dimensions, and alarm systems, ensuring operator safety during operation. With technical specifications including an operating pressure of 4,000 psi (27.5 MPa) and an operating weight of 18,370 lbs (8,332 kg), the TB180FR is a robust solution for intensive applications.
